Quick Details

  • Certification: ce
  • Capacity: 96
  • Power (W): 1200
  • Voltage (V): 220
  • Model Number: DYS-1024
  • Brand Name: DY or OEM
  • Place of Origin: Guangdong, China
  • Model: DYS-1024
  • Ultrasonic power: 1.2KW
  • Ultrasonic Frequency: 28or40KHz
  • Tank capacity: 96L
  • Timer: 1-60minutes
  • Heating power: 4KW
  • Tank size: 600*400*400mm
  • supply voltage: 220V
  • Material: stainless steel 304

Packaging & Delivery

Packaging Details Wooden case
Port SHENZHEN

96L Adopts Digital Display Timing and Mechanical temperature controller

Model:DYS1024


Product features:
1, The machine is made up of 304# stainless steel, durable, easy to operate, Connect the power can be used.
2, The machine uses 28KHz Ultrasonic generator, effectively reduce the noise and improve the cleaning efficiency.
3, cleaning time can be adjusted within 99 minutes, to clean the standard.
4, the machine is equipped with separate drainage ball valve manual.
5, Ultrasonic generator features: the use of new dual frequency circuit has: Power continuously adjustable, dual frequency sweep frequency tracking, digital display, digital display, digital display and digital display and timing cleaning functions. (according to the cleaning of different parts, to achieve the standard, uniform cleaning effect)
6, heating function: equipped with thermostatic temperature control device, to achieve the design temperature automatically stop heating, lower than the set temperature, automatic heating.
Technical parameters:
Model:DYS1024
Ultrasonic power:1200W
Ultrasonic Frequency: The default 28KHz (25KHz/40KHz/60KHz/68KHz delivery also can be customized according to the requirement)
Tank Capacity:96L
Timer:1~99min Digital display times.
Heating power: 4000W (heating power can be increased or reduced according to the requirement.
Heating control mode: mechanical temperature control temperature range 30℃ to 110℃.
The Tank size: 600 x 400 x 400 mm(L x W x H)
The shape size: 720 x 540 x 695 mm(L x W x H)
The supply voltage: AC 220V,50Hz
The Ultrasonic cleaner Random collocation cover.
There is drainage valve.
The basket can be optional.
Application range:
Applicable to electroplating products, stainless steel products, brass products, aluminum products, auto and motorcycle parts, metal stamping parts, electronic appliance parts, oil pump and nozzle, compressor parts, semiconductor wafer, electroplating industry before processing and chemical fiber industry of spinneret and filter cleaning. With special lotion effect is better. Can effectively remove the plating products, stainless steel products, brass products, aluminum products surface wax, the effect is quite good.
The cleaning of applicable in the manufacture of hardware, electronic circuit board, jewelry, watch parts, glasses, nail tattoo equipment, medical (surgical equipment cleaning and disinfection), chemical, automobile repair industry, biochemical medicine research institute and school laboratory (degassing, defoaming, emulsifying, mixing replacement cells crushed), etc.
